| TECHNICAL SPECIFICATION | |||||
|---|---|---|---|---|---|
| No. | Data Fields | No.Digit | LED Type | Color | Digit Height |
| 1 | MODEL | 8 Cha. | Dot-matrix 3mm | Red | 1 Inch |
| 2 | PLAN/TARGET | 4 | 7-Segment | Red | 2.3 Inch |
| 3 | ACTUAL | 4 | 7-Segment | Red | 2.3 Inch |
| 4 | DIFF. | 5 | 7-Segment | Red | 2.3 Inch |
| * Model can change Clock, Cycle Time, Daily Plan/Target, other | |||||
| INPUT TYPE | |||||
| Contact input (input by a relay or switch contact) | |||||
| DC voltage input: 5 to 24 VDC at "High" (logic) level and 0 to 2 VDC at "Low" (logic) level |
|||||
| ELECTRICAL SPECIFICATIONS | |||||
| Power Source : | 110-220 Volts AC / 50 Hz. | ||||
| Power Consumption : | Max. 65 Watts | ||||
| Current Draw : | 0.29 - 0.6 Amp. | ||||
| UL, CE Approve Listed Power : | Yes | ||||
| PHYSICAL SPECIFICATIONS | |||||
| Indoor / Outdoor : | Indoor | ||||
| Dimensions : | Width550 x Height 400 x Depth80 mm. | ||||
| Weight : | 7 kg. | ||||
| Viewing Distance : | Max. 30 m. | ||||
| LED / Acrylic Face Color : | Red (Standard) | ||||
| Enclosure Material : | Metal / Acrylic | ||||
| Enclosure Color : | Gray Color Powder-Coat Finish | ||||
| Mounting Method : | Top Mounting Bolts/Ceiling/Wall Mount | ||||
| Price : | ราคาพิเศษค่ะ | ||||
